Apem DPDT Slider Switch

		(0 reviews)

High quality DPDT slider switch. Mounting hole distance: 28mm. Works great as a replacement in Big Muff pedals and other vintage Electro Harmonix pedals.

Contact rating: 6 Amps at 125 VAC, 3 Amps at 250 VAC

Initial contact resistance: 30 milliohms max.

Insulation resistance: 100 megohms min. at 500 VDC

Dielectric strength: 1000 VAC for 1 minute (min.)

Electrical life: 10,000 cycles min.

Operating temperature range: -20°C to +60°C

Actuation force: 500g ± 200g

Solder heat resistance: 260°C max. for 3 seconds

Solvent washing permissible

Contacts: Silver plated phosphor bronze

Terminals: Tin plated brass

Actuator: Nylon, type 6/6

Base: Phenolic laminated sheet

Frame: Zinc plated steel

Wash-through open frame construction.

UL & CSA recognized.

Threaded mounting holes standard - M3X0.5. Screws not included. Add SKU 28887 to your order if you need any (other lengths are also available on the website)

Panel mounting.

May be used as a replacement for a Jaguar guitar switch. Caveat: it has a wider body (about 1 mm) than a stock MIJ Fender Jaguar switch. For the pickups control plate it's not a problem, but in the rhythm switch plate, it doesn't fit the cavity, you need to sand just about 0.5 mm off of the cavity wall.

SKU SKU 61760

Weight 6,00 g

360 Image

Manufacturer APEM GmbH, Paulsdorfferstr. 34, 81549 München, Deutschland, https://www.apem.com/idec-apem/de/support

Our price: €2,46
including VAT 19% , [plus shipping]
