NUX NMT1 Multitester

The NMT-1 can be used for testing 6,35mm TS and TRS audio cables as well as 2,1 mm DC power cables. With the NMT-1 you can easily test your solderless patch cables for correct connections and short circuits. No more confusion caused by inaccurate current specifications. Connect your pedal to the NMT-1 and you'll know how much current it actually needs and can adjust your pedal accordingly. As a bonus feature, the NMT-1 can also be used as a chromatic tuner. No need to carry an additional tuner; the NMT-1 can do it all.

The handy design is perfect for that final pre-performance check. It's so portable you can even carry it in your pocket.
The bright and large display allows you to easily read the information no matter where you are. With the built-in Li-on battery, you can conveniently charge the NMT-1 via the USB-C port.

Specifications:

Pedal current and voltage meter

Input voltage range: 9-28V DC

Maximum displayed current: 2A

Protection: The overvoltage warning is displayed when the input voltage exceeds 30 V.

The overcurrent warning is displayed when the input current exceeds 2.1 A.

Includes tuner

Tuning range: A0(27.5Hz)-C8(4186.0Hz)

Tuning mode: Chromatic

Tuning accuracy: ±1 cent

Power supply: Built-in Li-on battery, charging via USB-C port

Dimensions: 95mm(L)x71mm(W)x30mm(H)

Weight: 125g

USB-C charging cable (1) included

2.1mm DC cable (1) included
