Alpha 7-PC-5k lin

Alpha 7-PC-5k lin

(0 reviews)

Alpha 7mm potentiometer, full black flattened D-shaft. PC mount.

Specifications:

  • Mono
  • Plastic Axis, black
  • flattened D-Shaft
  • Rated wattage: 0,05W
  • Rated voltage: 100VAC
  • Insulation resistance: 100M Ohm at 250VDC
  • Breakdown voltage: 300VAC for 1 minute
  • Rotation angle: 300 degrees +/- 10%
  • Rotation torque: 10 to 150g/cm
  • Rotational life: 15000 cycles
  • Size (body) LxWxH: 7x7x5,3mm
  • Axis length (total including thread): 15mm
  • Thread length: 5mm
  • Length of flattened part of axis: 7mm
  • Axis diameter: 6,0mm

    • SKU SKU 34191
    Weight 7,00 g
    Our price: €7,21
    including VAT 19% , [plus shipping]
    Quantity Price*
    3-5 Items €6,88
    6-9 Items €6,58
    10+ Items €6,39

    *Note: including VAT , [plus shipping]

     Delivery time: 4-5 days*
