Nichicon KS 6800uF 35V

Nichicon KS 6800uF 35V

(0 reviews)

Nichicon KS Series 6800uF, 35VV DC.
Aluminium electrolytic capacitors. Dimensions (D x L) mm: 22 x 40mm.
  • Rated ripple current (Arms) at 85°C 120 Hz: 2,5

    Features
  • Snap-in Terminal Type, For Audio Equipment, Smaller-sized
  • Smaller and high-tone quality than KG series TYPE-1 grade
  • An effect to tone quallity improvement by replacement from a small standard product to use
  • Compliant to the RoHS directive (2011/65/EU)


    • Specifications
  • Category Temperature Range: - 40 to +85°C
  • Rated Voltage Range: 25 to 100V
  • Rated Capacitance Range: 680 to 33000uF
  • Capacitance Tolerance: ± 20% at 120Hz, 20°C
  • Leakage Current: After 1 minute's application of rated voltage, leakage current is not more than [sq. rt.(3CV)] uA, [C : Rated Capacitance(uF), V : Voltage ( V ) ]
  • Shelf Life: After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above
  • Marking: Printed with silver color letter on black sleeve
    • "

    SKU SKU 40533
    Weight 25,00 g
    360 Image 360 degrees image
    Our price: €6,83
    including VAT 19% , [plus shipping]
    Quantity Price*
    3-5 Items €6,52
    6-9 Items €6,18
    10+ Items €5,82

    *Note: including VAT , [plus shipping]

     Delivery time: 4-5 days*
