Ohmite Audio Gold 10W - 0,33 Ohm

Ohmite AG10 Audio Gold 10W - 0,33 Ohm. Size (LxD): 45,2x10,3mm. Voltage: 1000V. The Ohmite AG10 Audio Gold resistor has been designed for high-end audio amplifier and speaker applications. These resistors utilize high quality resistance wire, wound on a ceramic core, terminated, and finished with flameproof Centohm coating. The use of non-magnetic materials improves sound quality.
Audio Gold resistors are designed for use in cross-over networks and as source, emitter, or cathode resistors in balancing applications for output transducers

Features:

Non-magnetic materials

Mono-metallic design

Welded connections

Reduces signal distortion

Minimizes thermal EMF

Reduces current noise

Superior mid-range frequency performance

Improved stability

Specifications:

Resistor material: copper-nickel

Core: Ceramic

Coating: Centohm

Terminals: copper-nickel

Electrical tolerance: 5%

Temperature Coefficient: 50ppm/'C

Overload: 10x rated power for 5 sec.

Derating: Linearly from 100% @ 25'C to 0% @ 275'C
