Vishay Dale RH025 15 Ohm 25W

Vishay Dale RH025 15 Ohm 25W
Vishay DALE wirewound resistor. RH-25 series.

Specifications:

  • Hermetically sealed in aluminum enclosure
  • High performance heat sink
  • Suitable for chassis mounting to increase cooling effect
  • All connections have been spot-welded
  • MIL-Spec rating: MIL-PRF-18546
  • Tolerance: 1%
  • Power rating: 25W
  • Insulation resistance: >10^3 MOhm
  • Insulation voltage: 1000V eff
  • Temperature coefficient: +/- 20ppm/'C
  • Temperature range: -55...+250'C
  • Tensile-loaded capacity of terminals: 5lb
  • Lettering: Manufacturers logo, series, resistance, tolerance.

    • SKU SKU 49835
    Weight 10,00 g
    360 Image 360 degrees image
    Manufacturer Vishay Electronic GmbH, Hofmark-Aich-Str. 36, 84030 Landshut, Deutschland, https://www.vishay.com/en/company/contacts/
    Our price: €4,46
    including VAT 19% , [plus shipping]
    Quantity Price*
    5-9 Items €4,36
    10-24 Items €4,22
    25+ Items €4,11

    *Note: including VAT , [plus shipping]

     Delivery time: 4-5 days*
